BIOTECHSOLVENT DEGASSING

The Biotech DEGASi series of online degassers ensure efficient degasification of flowing liquids under a variety of conditions. Designed for different solvents and a wide range of flow rates, there is always a model that suits your needs for an efficient degassing process.

Biotech have set a new world standard for vacuum degassers with the introduction of the DEGASi PLUS series, and with the outstandingly powerful DEGASi PREP+ model, degasification of aqueous-organic solvents can now be accomplished at very high flow rates.

DEGASi PLUS Degassers

DEGASi PLUS Classic

This is the first choice for most applications in analytical instrumentation and chromatography. This state-of-the-art standalone degasser will provide you with trouble free and efficient degassing day after day.

With the highly permeable Systec AF™ membrane an internal degasser chamber volume of only 480µl is sufficient, to give you excellent degassing efficiency up to flow rates of approximately 3 ml/min.

PRODUCT FEATURES

• Very good chemical compatibility flow path
• Biocompatible flow path
• Ultra-high degassing efficiency
• Fits every system
• Long life expectancy 5+ years continuous (24/7) running capacity
• Easy to prime
• Almost silent
• Closed loop vacuum control means constant vacuum (variable RPM)
• ZHCR® patented control eliminates baseline fluctuations
• Continuous vacuum system monitoring to ensure optimum operational conditions are maintained
• Advanced error and leak checking functions
• CE & RoHS compliant

GENERAL SPECIFICATIONS

• Degassing Channel Tubing: Systec AF™ (0.045’’ ID)
• Maximum Channel Pressure: 70 PSI
• Wetted Materials: Systec AF™, PEEK, Glass-filled PTFE
• Liquid Connection: 1/4’’-28 UNF threaded flat-bottom port
• Size (L x H x W): 245 x 111 x 59 mm
• Internal Volume: 480µl

DEGASi PLUS GPC

DEGASi® PLUS GPC is the right choice of degasser if you are working with 100 % organic solvents in your fluidic line. Example of application areas where this degasser is successfully used are GPC (Gel Permeation Chromatography) and Normal Phase Chromatography.

DEGASi® PLUS GPC uses the same 480 µl Systec AF™ degassing membrane as used in DEGASi® Classic. The main difference compared with the DEGASi® Classic is that we use a stented version of the vacuum chamber in the DEGASi® GPC. The stent is a short piece of a stainless steel tube placed inside the ends of the degassing membrane, in order to make the internal ferrule in the bulkhead to get a better grip. This solution makes an even more secure internal connection when working with 100 % organic solvents in the fluidic line.

PRODUCT FEATURES

• Outstanding chemical compatibility flow path
• Ultra-high degassing efficiency
• Fits every system
• Long life expectancy 5+ years continuous (24/7) running capacity
• Easy to prime
• Almost silent
• Closed loop vacuum control means constant vacuum (variable RPM)
• ZHCR® patented control eliminates baselines fluctuations
• Excellent chemical compatibility flow path
• Continuous vacuum system monitoring to ensure optimum operational conditions are maintained
• Advanced error and leak checking functions
• CE & RoHS compliant

GENERAL SPECIFICATIONS

Degassing Channel Tubing: Systec AF™ (0.045’’ ID)

Maximum Channel Pressure: 70 PSI

Wetted Materials: Systec AF™, PPS, Glass-filled PTFE Stainless Steel

Liquid Connection: 1/4’’-28 UNF threaded flat-bottom port

Size (L x H x W): 245 x 111 x 59 mm

Internal Volume: 480µl

DEGASi Plus Micro

Are you working with very low flow rates? Do you want to minimize the dead volumes inside your system? Then DEGASi® MICRO is your number one choice of degasser. With only 100 µl internal volume you minimize the internal volume while still keeping excellent degassing efficiency up to approximately 0.5 ml/min

PRODUCT FEATURES

• Very good compatibility flow path
• Biocompatible flow path
• Ultra-high degassing efficiency
• Fits every system
• Long life expectancy 5+ years continuous (24/7) running capacity
• Easy to prime
• Almost silent
• Closed loop vacuum control means constant vacuum (variable RPM)
• ZHCR® patented control eliminates baseline fluctuations
• Continuous vacuum system monitoring to ensure that optimal operational conditions are maintained
• Advanced error and leak checking functions
• CE & RoHS compliant

GENERAL SPECIFICATIONS

Degassing Channel Tubing: Systec AF™ (0.045’’ ID)

Maximum Channel Pressure: 70 PSI

Wetted Materials: Systec AF™, PEEK, Glass-filled PTFE

Liquid Connection: 1/4’’-28 UNF threaded flat-bottom port

Size (L x H x W): 245 x 111 x 59 mm

Internal Volume: 100µl

DEGASi Plus Semi-Prep

When working with higher flow rates, up to 6 ml/min, the DEGASi® SEMI-PREP equipped with 925 µl degassing chambers is strongly recommend. These chambers can be used up to 10 ml/min but with a lower degassing efficiency.

PRODUCT FEATURES

• Very good chemical compatibility flow path.
• Biocompatible flow path.
• Ultra-high degassing efficiency.
• Fits every system.
• Long life expectancy: 5+ years continuous (24/7) running capacity.
• Almost silent.
• Closed loop vacuum control means constant vacuum (variable RPM)
• Easy to prime.
• ZHCR® patented control eliminates baseline fluctuations.
• Continuous vacuum system monitoring to ensure optimal operational conditions are maintained.
• Advanced error and leak checking functions.
• CE & RoHS compliant
• GPC-compatible version available

GENERAL SPECIFICATIONS

Degassing Channel Tubing: Systec AF™ (0.045’’ ID)

Maximum Channel Pressure: 70 PSI

Wetted Materials: Systec AF™, PEEK, Glass-filled PTFE

Liquid Connection: 1/4’’-28 UNF threaded flat-bottom port

Size (L x H x W):

245 x 111 x 59 mm

Internal Volume: 925µl

DEGASi® PREP

The DEGASi® PREP vacuum degassing system for analytical instrumentation and HPLC removes dissolved gasses at flow rates up to approximately 15-20 ml/min per channel. Built for the rigours of modern preparative and semi-prep scale HPLC, its unique design assures reliable continuous operation and the highest level of continuous performance available. The low internal volume (5.3mL) of each Systec AF™ channel offers quick equilibration and short startup times compared with PTFE degassers.

PRODUCT FEATURES

• Ultra-high degassing efficiency
• Low volume, easy to prime
• Dual lumen design for low-flow resistance
• ZHCR® patented control eliminates baseline fluctuations
• Inert flow path
• Long life expectancy – 5+ years continuous (24/7) running capacity
• Continuous vacuum system monitoring to ensure optimum operational conditions are maintained

GENERAL SPECIFICATIONS

Recommended Flow Rate: 15 ml/min (Per Channel)

Degassing Channel Tubing: Systec AF™ (0.075″e; ID)

Degassing Channel Pressure Rating: 70 PSI (testing pressure)

Wetted Materials: Systec AF™, PPS, Glass-filled PTFE

Liquid Connection: 1/4’’-28 UNF threaded flat-bottom port

Size (L x H x B):296 x 163 x 79 mm

Internal Volume: 5300µl

DEGASi PREP+

DEGASi® PREP+ uses a revolutionary new technology that makes it possible to degas organic solvents with higher flows in a cost-effective manner.

It is a perfect choice for efficient degassing of many types of liquids at high flow rates, up to 75-100 ml / min per chamber. Available in 1, 2 and 4 channels with an optional analytical flow chamber.

PRODUCT FEATURES

• Outstanding chemical compatibility flow path
• Ultra-high degassing efficiency
• New cost-effective technology

APPLICATIONS

• Preparative HPLC
• Flash chromatography
• High-throughput applications
• Dispensing applications
• Ink degassing – all types of ink including organic solvent based

GENERAL SPECIFICATIONS

Recommended Flow Rate: 75-100 mL/min (per channel)

Maximum Flow Rate: 200 ml/min (per channel)

Maximum Channel Pressure:50 PSI/3,5 bar

Wetted Materials: Systec AF™, FEP, Tefzel, PTFE and Glass-filled PPS

Liquid Connection: 1/4’’-28 Female Port

Pressure Drop: 0.0226 kPa/ml/min

Size (L x H x W):

295x110x80 mm (1-channel)

260x110x150 mm (2-channel)

260x110x290 mm (4-channel)

Internal Volume: 23ml

DEGASi COMPACT

The new white Biotech DEGASi® Compact is a new line of stand alone degassers which combine the cutting edge Systec technology with a very small footprint.

PRODUCT FEATURES

DEGASi® Compact is available with 2, 4 or 6 degassing channels in a housing with only 167 x 59 mm footprint. This is possible due to the development of a new single stage vacuum pump with a small built in control board and new 285 µl Systec AF™ vacuum chambers.

Closed-loop control with a continuously running vacuum pump gives a very smooth baseline. The speed of the pump is varied to maintain an exact vacuum level inside the vacuum chambers.

The degasser is equipped with built in error detection functionalities. A bi-colour diode on the front panel gives information about the performance. The extremely low internal volume of 285 µl provides very fast priming and start up. Despite the small size of the unit it has an expected life time of more than 6 years.

GENERAL SPECIFICATIONS

Degassing Channel Tubing: Systec AF™ (0.035’’ ID)

Degassing Channel Pressure Rating: 70 PSI (testing pressure)

Degasser nominal performance: 2ml/ min per channel

Wetted Materials: Systec AF™, PPS, PEEK, Glass-filled PTFE

Liquid Connection: 1/4’’-28 UNF threaded flat-bottom port

Size (L x H x B): 167 x 111 x 59 mm

Internal Volume: 285µl

DEGASI® HIGH FLOW 1000

If you are working with high flow applications like chemical analyses, biotechnology or sensitive processes on the manufacturing side, the new DEGASi® HIGH FLOW 1000 degasser will meet your expectations.

DEGASi® HIGH FLOW 1000 works with high flow rates and ultra-high degassing efficiency. With water-based solutions it removes dissolved gases at flow rates up to 1000 ml/min.

APPLICATIONS

• Clinical chemistry analysers
• Dispensing applications
• Dissolution testing
• Process applications
• High-throughput applications
• Ink degassing (Waterbased Ink)

The DEGASi HIGH FLOW is also avalible as an OEM version with an open-frame structure and uses a different power delivery.

GENERAL SPECIFICATIONS

Recommended Flow Rate: 0—1000 ml/min

Wetted Materials: Silicone, PVC, Nitrile Rubber,Polyamide

Applicable Solvents: Water and buffer solutions

Maximum Channel Pressure: 14 PSI/1 Bar

Pressure Drop: <20 kPa @600 mL/min

Liquid Connection: Barb for ID 10 mm tubing

Size (L x H x B, weight): 365x135x150mm, 5300g

Internal Volume: 200mL
